NX7002AK,215
Non-returnable
₹0.95
MOSFET Transistor, N Channel, 190 mA, 60 V, 3 ohm, 10 V, 1.6 V, NEXPERIA
Product Details
| Manufacturer Part Number: | NX7002AK,215 |
| Manufacturer: | NEXPERIA |
| FET Type: | N-Channel |
| Technology: | MOSFET |
| Drain to Source Voltage (Vdss): | 60 V |
| Current - Continuous Drain (Id) @ 25°C: | 190mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On): | 5V, 10V |
| Rds On (Max) @ Id, Vgs: | 4.5Ohm @ 100mA, 10V |
| Vgs(th) (Max) @ Id: | 2.1V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs: | 0.43 nC @ 4.5 V |
| Vgs (Max): | ±20V |
| Operating Temperature: | -55°C to 150°C |
| Mounting Type: | Surface Mount |
| Package: | TO-236AB |
