BSS138
Non-returnable
₹5.25
N-Channel 50V 170mA 350mW (Ta) Surface Mount SOT-23-3, onsemi
Product Details
| Manufacturer Part Number: | BSS138 |
| Manufacturer: | onsemi |
| Drain to Source Voltage (Vdss): | 50 V |
| Current - Continuous Drain (Id) @ 25°C: | 170mA |
| Drive Voltage (Max Rds On, Min Rds On): | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs: | 3Ohm @ 500mA, 10V |
| Vgs(th) (Max) @ Id: | 1.6V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs: | 2.4 nC @ 10 V |
| Vgs (Max): | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds: | 27 pF @ 25 V |
| Power Dissipation (Max): | 350mW (Ta) |
| Operating Temperature: | -55°C ~ 155°C |
| Mounting Type: | Surface Mount |
| Supplier Device Package: | SOT-23-3 |
