WPN4020H2R2MT
Non-returnable
₹14.05
2.2 μH Shielded Drum Core, Wirewound Inductor 4.3 A 48mOhm Max Nonstandard, Shenzhen Sunlord Electronics Co., Ltd.
Product Details
| Manufacturer Part Number: | WPN4020H2R2MT |
| Manufacturer: | Shenzhen Sunlord Electronics Co., Ltd. |
| Type: | Drum Core, Wirewound |
| Material - Core: | Ferrite |
| Inductance: | 2.2 µH, 2.2 uH |
| Tolerance: | ±20% |
| Current Rating (Amps): | 4.3 A |
| Current - Saturation (Isat): | 7.6 A |
| Shielding: | Shielded |
| DC Resistance (DCR): | 48mOhm Max |
| Frequency - Self Resonant: | 25 MHz |
| Operating Temperature: | -40°C ~ 125°C |
| Inductance Frequency - Test: | 1 MHz |
| Mounting Type: | Surface Mount |
| Package / Case: | Nonstandard |
