PH2-10-UA
Non-returnable
₹12.00
10P AU FLASH SINGLE / Headers & Wire Housings, Adam Tech
Product Details
| Manufacturer Part Number: | PH2-10-UA |
| Manufacturer: | Adam Tech |
| Connector Type: | Header |
| Contact Type: | Male Pin |
| Pitch - Mating: | 0.100" (2.54mm) |
| Number of Positions: | 10 |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.100" (2.54mm) |
| Mounting Type: | Through Hole |
| Contact Length - Mating: | 0.235" (5.97mm) |
| Contact Length - Post: | 0.120" (3.05mm) |
| Overall Contact Length: | 0.453" (11.50mm) |
| Insulation Height: | 0.098" (2.50mm) |
| Operating Temperature: | -55°C ~ 105°C |
| Material Flammability Rating: | UL94 V-0 |
| Insulation Color: | Black |
| Current Rating (Amps): | 3A |
| Voltage Rating: | 250VAC |
